Advantages

  • High Speed IGBT combined with SiC SB-Diode for recovery loss elimination
  • Compatible NX package
  • Low power loss at high switching frequency operation (fc: 20~60 kHz)
  • Optimized for trade-off of IGBT and Diode
  • Low thermal resistance and high power density by AlN ceramic substrate

Attributes

Ratings:

1200 V : 300 A

Dimensions [mm]:

62 x 152 x 17
