Catalogues

    • // Power Semiconductor Catalogues

      POWER MODULES

      Mitsubishi Electric power modules are at the forefront of the latest energy innovations that seek to solve global environmental issues while creating a more affluent and comfortable society for all. Some of these innovations are photovoltaic (PV) and wind power generation from renewable energy sources, smart grids realizing efficient supply of power, hybrid/electric vehicles (HVs/EVs) that take the next step in reducing carbon emissions and fuel consumption, and home appliances that achieve ground-breaking energy savings. Whether in appliances, railcars, EVs or industrial systems, our power modules are key elements in changing the way energy is used.

      Download PDF
    • // Power Semiconductor Catalogues

      HVIC Catalogue and Line-up

      High-voltage integrated circuits (HVICs) are capable of driving the gates of power MOSFETs and IGBTs using signals input from microcomputers, thereby replacing power MOSFET and IGBT gate drivers that use pulse transformers and photocouplers. They are insulated by a level shift circuit inside the semiconductor chip. Since a variety of protection functions, such as power supply undervoltage, interlocking, input signal filter, and error output, are built into the IC, reliability of the power supply equipment is enhanced. Mitsubishi Electric has many half-bridge products that are commonly used in drive circuits. Our HVIC products comply with the European Union’s Restriction of Hazardous Substances Directive for electrical equipment, 2011/65/EU and 2015/863/EU.

      Download PDF
