Key Product Features

  • Low power loss CSTBTTM chip technology
  • High reliability wire bond less, Direct Lead Bonding (DLB) package
  • Extra-compact direct cooling 6-in-1 package with cooling fin
  • Solder-free insulation through high thermal conductivity substrate
  • Integrated on-chip temperature sensor
  • Integrated on-chip current sensor
  • Pb-free, RoHS compliant structure

Contact us

Mitsubishi Electric Europe B.V.
Semiconductor European Business Group
Mitsubishi-Electric-Platz 1
D – 40882 Ratingen

Phone: +49 (0) 2102 / 486 – 0
Fax: +49 (0) 2102 / 486 – 4140

E-Mail: semis.info@meg.mee.com
Internet: www.meu-semiconductor.eu

I am looking for ...

    IGBT for Automotive

    • 6-in-1

      J3-Series (RC-IGBT J3-HEXA-L)

      Ratings

      750V: 800A

      Dimensions [mm]

      87 x 193 x 13

    • 6-in-1

      J3-Series (RC-IGBT J3-HEXA-S)

      Ratings

      750V: 400A

      Dimensions [mm]

      87 x 111 x 14

    • 2-in-1

      J3-Series (RC-IGBT J3-T-PM)

      Ratings

      750V: 400A

      Dimensions [mm]

      27 x 54 x 7

    • 6-in-1

      J1-Series

      Ratings

      650 V : 600 A , 700A

      Dimensions [mm]

      115 x 120 x 18.9

    SiC for Automotive

    • 6-in-1

      J3-Series (SiC J3-HEXA-L)

      Ratings

      1300V: 700A

      Dimensions [mm]

      87 x 193 x 13

    • 6-in-1

      J3-Series (SiC J3-HEXA-S)

      Ratings

      1300V: 350A

      Dimensions [mm]

      87 x 111 x 14

    • 2-in-1

      J3-Series (SiC J3-T-PM)

      Ratings

      1300V: 350A

      Dimensions [mm]

      27 x 54 x 7

    • 2-in-1

      J3-Series SiC Relay

      Ratings

      1300V: 250 A / 350 A

      Dimensions [mm]

      27 x 54 x 7

    Driver IC for Automotive

    • 1-in-1

      J1A-Series Driver IC

      Ratings

      M81603JFP and M81605JFP

      Dimensions [mm]

      9 x 9 x 1.7
