Advantages

  • Compact design with integrated inverter and Brake
  • Integrated HVIC & LVIC
  • Dedicated protection functions: short circuit and under voltage
  • Operation at Tc,Max= 110ᵒC
  • High Isolation Voltage Viso = 2500Vrms
  • Same Package size for 6 different power ratings

Attributes

Ratings:

1200 V : 5 A, 10 A, 15 A, 25 A, 35 A
600 V : 50 A

Dimensions [mm]:

34 x 85 x 5.7

Downloads

3D-Model

Presentations
